Low Noise Oil Free Piston Compressor

TECHNICAL SPECIFICATIONS :

Max. Air PRESSURE -120 PSI (8.0 Kg. /Cm2)
Free Air Displacement 130 LMP (4.6 C.F.M.)
Electrical -1H.P. 230V,1Ph -50Hz RPM -1440 AMP 3

PERFORMANCE CHART :

COMPRESSOR PERFORMANCE WITH 5 LTRS. RECEIVER
PSIG Vs LPM
PSIG - 0	20	40	60	80
LPM - 100	85	75	65	55

PHYSICAL DIMENSIONS OF COMPRESSOR WITH 5 LTRS. AIR RECEIVER :-
LENGTH - 17" WIDTH - 15" HEIGHT-13" WEIGHT - 20KGS.

TECHNICAL SPECIFICATIONS :

Max. Air PRESSURE -120 PSI (8.0 Kg. /Cm2)
Free Air Displacement 130 LMP (4.6 C.F.M.)
Electrical -1H.P. 230V,1Ph -50Hz
RPM -1440 AMP 3

PERFORMANCE CHART :

COMPRESSOR PERFORMANCE WITH 20 LTRS. RECEIVER
PSIG Vs LPM
PSIG - 0	20	40	60	80
LPM - 100	85	75	65	55

PHYSICAL DIMENSIONS OF COMPRESSOR WITH 20 LTRS. AIR RECEIVER :-
HEIGHT - 26" WIDTH - 17" LENGTH - 17" WEIGHT - 40KGS.

TECHNICAL SPECIFICATIONS :

Max. Air PRESSURE -120 Psl (8.0 Kg. /Cm2)
Free Air Displacement 150 LMP (5.3 C.F.M.)
Electrical -2H.P. 230V,1Ph -50Hz
RPM-1440 AMPS4.5

PERFORMANCE CHART :

COMPRESSOR PERFORMANCE WITH 40 LTRS. RECEIVER
PSIG Vs LPM
PSIG - 0	20	40	60	80	100
LPM - 145	135	125	115	105	95

PHYSICAL DIMENSIONS OF COMPRESSOR WITH 40 LTRS. AIR RECEIVER :-
LENGTH - 28" WIDTH - 30" HEIGHT - 29" WEIGHT - 56KGS
